Quick Details
Place of Origin:Zhejiang, China Brand Name:*****
Model Number:******** certificate:******
Type:Water Meters Product name:***********
Supply Ability
Supply Ability 100000 Piece/Pieces per Month The water meter can be produced in a hurry
Packaging & Delivery
Packaging Details Conventional packing of water meter:OUTER CARTON: 10 pcs/ctn
INNER CARTON: 1 pc/ctn
Port Ningbo
Lead Time: 30days
Multi Jet Residential Cold Water Meter
APPLICATION _____________________________________________________
Measuring the volume of cold potable water passing through the pipeline
FEATURES ________________________________________________________
1/ Dry type, magnetic drive, antimagnetic function
2/ Pointer-roller indicator, easy and long term clear reading
3/ Frost resistance, long work life
4/ Available non-return valve, inlet strainer and pulse output on request.
5/ Class C water meter is available for 15mm (1/2 inch), 20mm (3/4 inch) and 25mm (1 inch).
6/ ISO 4064 & ISO 9001
WORKING CONDITION______________________________________________
Water temperature≤50 for cold water meter
≤90 for hot water meter
Water pressure≤1MPa or 1.6MPa optional
(10bar or 16bar optional)
MAXIMUM PERMISSIBLE ERROR____________________________________
In the lower zone from Qmin inclusive up to but excluding Qt is ±5% _ In the upper zone from Qt inclusive up to and including Qs is: cold water meter ±2%, hot water meter ±3%.
MAIN TECHNICAL DATA____________________________________________
| Type | Size(mm) | Class | Qn Max. Flow | Qp Nominal Flow | Qn Transitional Flow | Qmin Min. Flow | Min. Reading | Max. Reading |
| M3/h | L/h | M3 | ||||||
| 2004(15e) | A | |||||||
| B | ||||||||
| C | ||||||||
| 2004(20e) | A | |||||||
| B | ||||||||
| C | ||||||||
| 2004(25f) | A | |||||||
| B | ||||||||
| C | ||||||||
