Model NO.
SRJ-36
Supply Ability:
10000 / Month
Stock Time:
30 Days
Quantity:

Quick Details
Place of Origin:Zhejiang, China              Brand Name:sierjia
Model Number:
Rotary Piston Volumetric Water Meter         certificate:CE
Type:Water Meters                             Product name:
Rotary Piston Volumetric Water Meter
Supply Ability
Supply Ability       100000 Piece/Pieces per Month The water meter can be produced in a hurry
Packaging & Delivery
Packaging Details   Conventional packing of water meter:OUTER CARTON: 10 pcs/ctn
INNER CARTON: 1 pc/ctn
Port                 Ningbo

Lead Time:          30days



APPLICATION  __--Measuring the total volume of cold potable water passing through the pipeline.______

Measuring the volume of cold potable water passing through the  pipeline


Feature:
--Volumetric meter, on principle of piston rotation, complies with ISO4064 Class C(R160)standard;
--High sensitivity, accurate measurement even at low flow rate of 4L/h;
--Optimum accuracy and performance at all times, in any position;
--Liquid-sealed register(LXH), vacuum sealed(LXHG)easy and long term clear reading.
--Piston adopts high quality material to ensure stable and durable performance;
--Data Output Options: 10 L/Pulse, 100 L/Pulse, or 1000 L/Pulse for LXHG; 1 L/Pulse for LXH.

Working condition:
Water temperature: 0.1°C~50°C for cold water meter.
Water pressure : ≤1.0Mpa
Compliance with standard: ISO4064(GB/T778.1-1996) ISO4064(GB/T778.1-2007)

Maximum permissible error:
(1) in the lower zone from Qmin(Q1) inclusive up to but excluding Qt(Q2) is ±5%.
(2) in the upper zone from Qt(Q2) inclusive up to and including Qs(Q4) is ±2%;

MAIN TECHNICAL DATA____________________________________________
